SoundTouch Device Initial Setup Variants

Based on community research from the SoundCork and ÜberBöse API projects, as well as analysis of the Stockholm firmware (firmware/Stockholm/.../setup/), this document outlines the methods used for the “out-of-the-box” setup of SoundTouch devices.

Setup Overview

Initial setup is the process of connecting a new or factory-reset device to a local Wi-Fi network and a Bose (or custom) account. This is distinct from the “Migration” process (handled by soundtouch-service), which redirects an already-configured device to a new server.

1. Bluetooth Low Energy (BLE) Setup

Used by most modern SoundTouch devices (ST-10, ST-20/30 Series III, SoundTouch 300).

Mechanism: The SoundTouch app communicates with the device over BLE to exchange Wi-Fi credentials.
Protocol: Internal research refers to this as the Gabbo protocol (see gabbo_setup_bco.js in firmware).
Process:
1. Put the device in setup mode (usually by holding the ‘2’ and ‘-‘ buttons).
2. The app discovers the device via BLE.
3. The app sends the Wi-Fi SSID and Password to the device.
4. The device connects to Wi-Fi and disables BLE setup.

2. Access Point (AP) Mode / Web Setup

The classic “failover” or “alternate” setup method.

Mechanism: The device creates its own Wi-Fi network (SSID: Bose SoundTouch ... or Bose Home Speaker ...).
IP Address: Typically 192.0.2.1 (device-side, verified on ST10).
Web Interface: The device hosts a web server on port 80.
Process:
1. Connect a PC/Phone to the device’s Wi-Fi.
2. Open a browser to http://192.0.2.1.
3. The device serves a Wi-Fi setup form — enter your home network SSID and password and click Submit.
4. The device disconnects from AP mode and joins your home network within ~15–30 seconds.

Speaker AP mode Wi-Fi setup page at 192.0.2.1

For command-line provisioning (without a browser), see §6 below.

3. Wireless Accessory Configuration (WAC)

Specific to Apple iOS devices.

Mechanism: Uses Apple’s MFi/WAC protocol to pass Wi-Fi settings from an iPhone/iPad directly to the device without manual password entry.
Status: Detected automatically by iOS when a new SoundTouch device is in setup mode.

4. USB Setup (Legacy)

Primarily used for older SoundTouch Series I and II devices or as a last resort.

Mechanism: Physical connection via Micro-USB to a computer running the SoundTouch Setup application.
Process:
1. Connect USB cable.
2. The desktop app communicates via a proprietary HID or Serial-over-USB protocol.
3. The app pushes Wi-Fi credentials.
4. References to this exist in the firmware as lost_USB_connection and connect_device (see setup_wizard.xml).

Technical Details: The “Gabbo” Protocol

The Stockholm firmware contains references to a communication layer called Gabbo.

File: setup/js/gabbo_setup_bco.js
Function: Handles the state machine for Wi-Fi connection, account pairing, and error handling during setup.
Relationship: It appears to be an internal wrapper for the messages sent between the setup client (App or Browser) and the device firmware.

Redirection during Setup

While the soundtouch-service focuses on migrating existing devices, a truly “clean” setup to a custom service would require:

Intercepting the initial account pairing request.
Providing a mock “Marge” service that accepts any credentials.
Patching the SoundTouchSdkPrivateCfg.xml during or immediately after the Wi-Fi connection phase.

5. Factory Reset Button Sequences

A factory reset wipes Wi-Fi credentials, account pairing, and all presets, returning the device to out-of-box state. The exact sequence varies by hardware generation.

Sequences verified against official Bose reset guides in firmware/FirmwareUpdateGuide/. Confirm the reset succeeded by watching the status LEDs and by verifying the Wi-Fi indicator glows solid amber (setup mode).

Model	Factory Restore Sequence	Confirm
SoundTouch 10	Power on; hold Preset 1 + Volume − for 10 s	Wi-Fi indicator glows solid amber
SoundTouch 20	Power on; hold Preset 1 + Volume − for 10 s	Lights blink L→R, then solid amber
SoundTouch 20 Series III	Hold Preset 1 + Preset 6 simultaneously for ~10 s	White LED sweep
SoundTouch 30 Series III	Hold Preset 1 + Preset 6 simultaneously for ~10 s	White LED sweep
SoundTouch 300	Hold Volume − until light bar blinks rapidly (~15 s)	Rapid blink → off → on
SoundTouch 10 (alt)	Press and hold the back recessed Reset pinhole for 10 s	Status LED restarts
SoundTouch 20 (soft)	Hold AUX for 15 s until display goes blank (settings preserved)	Display blanks

After factory restore the speaker enters setup mode automatically; no power-cycle is needed.

6. AP Mode Wi-Fi Provisioning via Console

When BLE is unavailable (e.g. when using an Android emulator), use AP mode to push Wi-Fi credentials from the Mac command line.

6.1 Connect Mac to Speaker AP

After factory reset the speaker broadcasts an SSID like Bose SoundTouch XXXX. Connect the Mac to it:

# List nearby SSIDs — use System Settings → Wi-Fi (the airport command was removed in macOS Sequoia+)
# Connect (replace with actual SSID)
networksetup -setairportnetwork en0 "Bose SoundTouch XXXX"

The speaker’s web UI gateway is at 192.0.2.1 (verified: ST10 assigns 192.0.2.2 to the client via DHCP).

# Confirm reachability
curl -sv http://192.0.2.1/ 2>&1 | head -40

6.2 Trigger Wi-Fi Site Survey (Optional)

The setup web UI at http://192.0.2.1/ uses the SoundTouch API on port 8090 — the same API as normal device operation. Trigger a network scan first so the speaker finds your SSID:

curl -s -X POST http://192.0.2.1:8090/performWirelessSiteSurvey \
  -H 'Content-Type: text/xml' \
  --data-raw '<PerformWirelessSiteSurvey timeout="5"/>'

6.3 Push Home Wi-Fi Credentials

HOME_SSID="MyHomeNetwork"
HOME_PASS="MyPassword"

curl -s -X POST http://192.0.2.1:8090/addWirelessProfile \
  -H 'Content-Type: text/xml' \
  --data-raw "<AddWirelessProfile><profile ssid=\"${HOME_SSID}\" password=\"${HOME_PASS}\" securityType=\"wpa_or_wpa2\" /></AddWirelessProfile>"

Expected response: <?xml version="1.0" encoding="UTF-8" ?><AddWirelessProfileResponse />

The speaker will disconnect from AP mode and join the home network within ~15–30 s.

6.4 Reconnect Mac to Home Network

networksetup -setairportnetwork en0 "MyHomeNetwork" "MyPassword"

Wait ~15 s for the speaker to join the home network, then verify:

# Discover the speaker's new IP via mDNS
dns-sd -B _soundtouch._tcp local &
sleep 5 ; kill %1

Comparison: Initial Setup vs. Migration

Feature	Initial Setup	Migration (soundtouch-service)
Connectivity	BLE, AP Mode, USB, WAC	Ethernet/Wi-Fi (existing)
Credentials	Required (SSID/Pass)	Not required (uses existing)
Access	Web UI / App protocol	SSH (root)
Primary File	`setup/index.html`	`SoundTouchSdkPrivateCfg.xml`
Use Case	Out-of-the-box / Reset	Redirecting active devices
